FR4 Rigid PCB

FR4 Rigid PCB

FR4 Rigid PCB is Solid, inflexible Printed Circuit Board. PCB can be Single or Double Sided PCB or Multilayer PCB.At the same time a Printed Circuit Board can be Rigid, Flexible or Rigid-Flex (Combination of Rigid and Flexible PCB). So, Rigid Circuit Board is a Board that we cannot bend or force out of shape. It is not flexible.

Send Inquiry

Product Description

1. Product Introduction of the FR4 Rigid PCB

Quint tech offer PCB production services from 1-36 layers, material could be FR4,High TG FR4,rigid PCB.

2. Product feature and application of the FR4 Rigid PCB

Max Rigid PCB size
1100*650mm, Min PCB size: 5*10mm
Min board thickness
0.3mm (2 layers)/ 0.5mm (4 layers)/0.8mm (6 layers)/ 1.2mm (10 layers)/1.3mm (12 layers)/1.5mm (14 layers)/1.7mm (6 layers)/1.8mm/2.0mm (18 layers)/2.2mm (20 layers)/2.4mm(22 layers)/2.6mm (24 layers), etc
The tolerance of board thickness
board thickness>1.0mm,±10%,board thickness≦1.0mm,±0.1mm.
Max copper thickness
8oz/inner layer,8oz/out layer
Min inner line width/space

3. Product Qualification of FR4 Rigid PCB

During the FR4 Rigid PCB production, we have circuit test-Withstand voltage test-OSP.

After these test, there have FQC-FQA-Pack-shiping.
